Festool S8 HW 30° D25-KL OFK Chamfer Router Cutter with Guide Bearing 8 mm Shank

Overview

Festool Chamfer Cutter S8 HW 30° D25-KL OFK At a Glance: 30° carbide chamfer cutter with a 25 mm cutting diameter, 8 mm shank and supplied steel guide bearing. For edge trimming on suitable plastic and solid-wood edges. Create a consistent bevel on exposed edges with the Festool S8 HW 30° D25-KL OFK chamfer cutter. Designed for edge trimming, it provides a defined angled finish on suitable plastic edging and solid-wood edges, making it useful for furniture components, cabinetry and general edge detailing. Adjust the router position to control how much of the profile engages the workpiece. The supplied steel ball bearing follows a suitable reference edge, helping maintain the cutter’s position along straight sections and compatible curves. The optimised bearing mount also permits operation without the bearing when the router is guided by an appropriate alternative arrangement. Its 8 mm shank fits the correct collet on the listed Festool routers and edge routers. A Defined Chamfer for Neat Edge Detailing A chamfer creates a flat angled face along an edge. This cutter’s fixed 30° geometry establishes the profile angle, while the routing setup determines the size of the finished bevel. Product Highlights • 30° chamfer geometry: Produces a defined bevel for edge trimming and detailing. • Carbide cutting material: HW cutting edges for the intended woodworking and plastic-edge applications. • Guide bearing included: Supplied with a sturdy steel ball bearing. • Flexible guidance: Can be used with the bearing or with suitable alternative guidance when the bearing is removed. • 25 mm cutting diameter: Compact cutter format for compatible routing setups. • 8 mm shank: For routers equipped with the correct 8 mm collet. Product Compatibility • Festool OF 1010: Compatible with the appropriate 8 mm collet and routing setup. • Festool OF 1010 R: Suitable for the corresponding router configuration. • Festool OFK 700: For compatible edge-routing applications. • Festool MFK 700: For the appropriate table, collet and guidance arrangement. • Festool MFKC 700: Compatible with the required 8 mm mounting and working configuration. • Material applications: Suitable plastic edges and solid-wood edges. Compatibility note: Check the router’s collet, cutter clearance and operating requirements before fitting. The 8 mm shank requires an 8 mm collet and must not be clamped in a 1/4-inch collet. When working without the bearing, use an approved alternative guidance method.
